Backlight Color: Pure White LED
Display Resolution: 800 × 480
Screen Brightness: >1200 nits
Viewing Angles: 50° top • 60° bottom • 70° left/right
Bluetooth: Integrated Bluetooth 4.0 (Bluetooth Classic)
Ethernet Ports: 1 × 100 Mbit
Wi-Fi: Internal 802.11 b/g/n
NMEA 2000 Connectivity: 1 × Micro-C
NMEA 0183 Support: None
PC Connectivity: None
Video: None
NMEA 2000 PGNs: • Receive Only: 65240 ISO Commanded Address • 127245 Rudder • 127251 Rate of Turn • 127257 Attitude • 127488 Engine Params Rapid Update • 127489 Engine Params Dynamic • 127493 Transmission Params Dynamic • 127505 Fluid Level • 127508 Battery Status • 129033 Time & Date • 129038 AIS Class A • 129039 AIS Class B • 129040 AIS Class B Extended • 129794 AIS Static/Voyage • 129801 AIS Address Safety • 129802 AIS Safety Broadcast • 129808 DSC Call • 130313 Humidity • 130314 Actual Pressure • 130576 Small Craft Status • 65285 Temperature w/ Instance • 65325 Reprogramming Status • 65480 Parameter Reply • 130817 Product Info • 130820 Reprogramming Status • 130832 Fuel Used High Res • 130834 Engine/Tank Config • 130838 Fluid Level Warning • 130842 AIS/VHF Message Transport • 130843 Sonar Status • Transmit & Receive: 59392 ISO Ack • 59904 ISO Request • 60160 ISO Data Transfer • 60416 ISO Connection Mgmt • 60928 ISO Address Claim • 126208 Group Function • 126464 PGN Group Function • 126992 System Time • 126996 Product Info • 127237 Heading/Track Control • 127250 Vessel Heading • 127258 Magnetic Variation • 128259 Speed • 128267 Water Depth • 128275 Distance Log • 129025 Position Rapid Update • 120296 COG/SOG Rapid Update • 129029 GNSS Position • 129283 XTE • 129284 Nav Data • 129539 GNSS DOPs • 129540 GNSS Sats in View • 130074 Route/WP List • 130310 Environmental Params • 130311 Environmental Params • 130312 Temperature • 130577 Direction Data • 61184 Parameter Command • 65292 Clear Fluid Warnings • 65293 LGC-2000 Config • 65323 Data User Group Request • 130831 Suzuki EP-20 / EP-50 Config • 130835 Set Engine/Tank Config • 130839 EP-45 Pressure Config • 130840 Data User Group Config • 130845 Parameter Handle • 130850 Event Command • 130851 Event Reply • Transmit Only: 65287 Temperature Config • 65289 Trim Tab Config • 65290 Paddle Wheel Speed Config • 130818 Reprogramming Data • 130819 Request Reprogram • 130828 Set Serial Number • 130836 Fluid Level Config • 130837 Fuel Flow Turbine Config
Power Consumption (Max): 2.0A @ 13V DC
Power Consumption (Typical): 2.0A @ 13V DC
Recommended Fuse: 3A
Supply Voltage: 12V DC (10.8–17V DC)
Humidity: 60°C • 95% RH for 18 hrs
Operating Temperature Range: 5°F to 131°F (-15°C to 55°C)
Shock & Vibration: 100,000 cycles • 20 G
Storage Temperature Range: 4°F to 140°F (-20°C to 60°C)
Waterproof Rating: IPX7 (card door closed)
Compass Safe Distance: 12" (300 mm)
Dimensions (W × H × D): 56 × 56 × 51
Mounting Type: Gimbal bracket or dash flush mount
Weight: 10
Radar Output Power: 1 kW capable (depends on connected transducer)
Interface: Multi-touch touchscreen • Zoom +/- • MOB (+/- combined) • Pages • Waypoint • Light/Power
Languages: Standard • Asian • Eastern European • Russia/Ukraine • Middle Eastern packs
Warranty: 2-year standard + 3-year upgrade option (total 5 years)
