<div class="metafield-rich_text_field"><h3>General</h3><p><strong>Dimensions:</strong> 16.9" x 10.5" x 3.14" (43.0 x 26.6 x 8.0 cm)</p><p><strong>Weight:</strong> 9.5 lbs (4.31 kg)</p><p><strong>Water Rating:</strong> IPX7</p><h3>Touchscreen</h3><p><strong>Display Type:</strong> FHD, IPS</p><p><strong>Display Size:</strong> 13.6" x 7.7"; 15.6" diagonal (34.5 x 19.5 cm; 39.7 cm diagonal)</p><p><strong>Display Resolution:</strong> 1920 x 1080 pixels</p><p><strong>Mounting Options:</strong> Bail or flush</p><p><strong>Input:</strong> Touchscreen with Keyed Assist</p><h3>Maps & Memory</h3><p><strong>Accepts Data Cards:</strong> 2 microSD™ cards</p><p><strong>Waypoints:</strong> 5,000</p><p><strong>Track Points:</strong> 50,000</p><p><strong>Tracks:</strong> 50 saved tracks</p><p><strong>Navigation Routes:</strong> 100</p><h3>Sensors</h3><p><strong>Included Sensors:</strong></p><p>• GPS<br />
<br />
• GLONASS<br />
<br />
• Galileo<br />
<br />
• BeiDou</p><p><strong>Has Built-in Receiver:</strong> Yes</p><p><strong>Receiver:</strong> 10 Hz</p><p><strong>NMEA 2000 Compatible:</strong> Yes</p><p><strong>NMEA 0183 Compatible:</strong> Yes</p><p><strong>Supports WAAS:</strong> Yes</p><p><strong>Supports Multi-band, Multi-constellation GPS:</strong> Yes</p><h3>Built-in Maps</h3><p><strong>Features:</strong></p><p>• Built-in Auto Guidance+: Yes (see Additional)<br />
<br />
• Garmin Navionics+ Inland & Coastal: Yes (see Additional)<br />
<br />
• Tide Tables: Yes (see Additional)</p><h3>Optional Map Support</h3><p><strong>Supported Maps:</strong></p><p>• BlueChart g3<br />
<br />
• BlueChart g3 Vision<br />
<br />
• LakeVü g3<br />
<br />
• LakeVü g3 Ultra<br />
<br />
• Garmin Navionics+™<br />
<br />
• Garmin Navionics Vision+™<br />
<br />
• TOPO 100K<br />
<br />
• Standard Mapping<br />
<br />
• Garmin Quickdraw Contours</p><h3>Chartplotter Features</h3><p><strong>Included Features:</strong></p><p>• AIS<br />
<br />
• DSC<br />
<br />
• Supports Fusion-Link™ compatible radios<br />
<br />
• ActiveCaptain® compatible: Yes<br />
<br />
• Supports Voice Commands<br />
<br />
• Sailing Features</p><h3>Electrical Features</h3><p><strong>Power Input:</strong> 9 to 18 Vdc</p><p><strong>Typical Current Draw at 12 Vdc:</strong> 3.9 A</p><p><strong>Maximum Current Draw at 12 Vdc:</strong> 6.6 A</p><p><strong>Maximum Power Usage at 10 Vdc:</strong> 48 W</p><h3>Sonar Features</h3><p><strong>Displays Sonar:</strong> Yes</p><p><strong>Power Output:</strong> 600 W</p><p><strong>Traditional Sonar (dual frequency/beam):</strong> Built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP)</p><p><strong>ClearVü:</strong> Built-in 260/455/800/1000/1200 kHz</p><p><strong>SideVü:</strong> Built-in 260/455/800/1000/1200 kHz</p><p><strong>Panoptix™ Sonar:</strong> No</p><p><strong>LiveScope:</strong> No</p><h3>Connections</h3><p><strong>Connection Options:</strong></p><p>• NMEA 2000® Ports: 1<br />
<br />
• Video Output Ports: 1 HDMI<br />
<br />
• Garmin Marine Network Ports: 2 (large connector)<br />
<br />
• 12-pin Transducer Ports: 12-pin scanning sonar<br />
<br />
• Bluetooth® Pairing<br />
<br />
• ANT® Connectivity<br />
<br />
• Garmin Wi-Fi Network (Local Connection)</p></div>
