<div class="metafield-rich_text_field"><h3>General</h3><p><strong>Dimensions:</strong> 11.6" x 7.7" x 3.9" (29.5 x 19.5 x 9.8 cm)</p><p><strong>Weight:</strong> 4.0 lbs (1.8 kg)</p><p><strong>Water Rating:</strong> IPX7</p><h3>Touchscreen</h3><p><strong>Display Type:</strong> WXGA, IPS</p><p><strong>Display Size:</strong> 8.5" x 5.4"; 10" diagonal (21.7 x 13.6 cm; 25.4 cm diagonal)</p><p><strong>Display Resolution:</strong> 1280 x 800 pixels</p><p><strong>Mounting Options:</strong> Bail or flush</p><p><strong>Input:</strong> Touchscreen with Keyed Assist</p><h3>Maps & Memory</h3><p><strong>Accepts Data Cards:</strong> 2 microSD cards</p><p><strong>Waypoints:</strong> 5,000</p><p><strong>Track Points:</strong> 50,000</p><p><strong>Tracks:</strong> 50 saved tracks</p><p><strong>Navigation Routes:</strong> 100</p><h3>Sensors</h3><p><strong>Included Sensors:</strong><br />
<br />
• GPS<br />
<br />
• GLONASS<br />
<br />
• Galileo<br />
<br />
• BeiDou</p><p><strong>Has Built-in Receiver:</strong> Yes</p><p><strong>Receiver:</strong> 10 Hz</p><p><strong>NMEA 2000 Compatible:</strong> Yes</p><p><strong>Supports WAAS:</strong> Yes</p><p><strong>Supports Multi-band, Multi-constellation GPS:</strong> Yes</p><h3>Optional Map Support</h3><p><strong>Supported Maps:</strong><br />
<br />
• BlueChart g3<br />
<br />
• BlueChart g3 Vision<br />
<br />
• Garmin Navionics+™<br />
<br />
• Garmin Navionics Vision+™<br />
<br />
• TOPO 100K<br />
<br />
• Standard Mapping<br />
<br />
• Garmin Quickdraw Contours</p><h3>Chartplotter Features</h3><p><strong>Included Features:</strong><br />
<br />
• AIS<br />
<br />
• DSC<br />
<br />
• Supports Fusion-Link™ compatible radios<br />
<br />
• ActiveCaptain® compatible: Yes<br />
<br />
• Sailing Features</p><h3>Electrical Features</h3><p><strong>Power Input:</strong> 9 to 18 Vdc</p><p><strong>Typical Current Draw at 12 Vdc:</strong> 2.3 A</p><p><strong>Maximum Current Draw at 12 Vdc:</strong> 5.0 A</p><p><strong>Maximum Power Usage at 10 Vdc:</strong> 34 W</p><h3>Sonar Features</h3><p><strong>Displays Sonar:</strong> Yes</p><p><strong>Power Output:</strong> 600 W</p><p><strong>Traditional Sonar (dual frequency/beam):</strong> Built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP)</p><p><strong>ClearVü:</strong> Built-in 260/455/800/1000/1200 kHz</p><p><strong>SideVü:</strong> Built-in 260/455/800/1000/1200 kHz</p><p><strong>Panoptix™ Sonar:</strong> No</p><p><strong>LiveScope:</strong> No</p><h3>Connections</h3><p><strong>Connection Options:</strong><br />
<br />
• NMEA 2000® Ports: 1<br />
<br />
• Garmin Marine Network Ports: 2 (large connector)<br />
<br />
• 12-pin Transducer Ports: 12-pin scanning sonar<br />
<br />
• ANT® Connectivity<br />
<br />
• Garmin Wi-Fi Network (Local Connection)</p></div>
