<div class="metafield-rich_text_field"><h3>General</h3><p><strong>Dimensions:</strong> 9.1" x 5.6" x 2.6" (23.2 x 14.3 x 6.7 cm)</p><p><strong>Weight:</strong> 1.5 lbs (0.7 kg)</p><p><strong>Water Rating:</strong> IPX7</p><p><strong>Display Type:</strong> WVGA, TN</p><p><strong>Display Size:</strong> 6.1" x 3.4" (15.5 x 8.7 cm)</p><p><strong>Display Resolution:</strong> 800 x 480 pixels</p><p><strong>Mounting Options:</strong> Bail or flush</p><p><strong>Input:</strong> Keyed</p><h3>Maps & Memory</h3><p><strong>Accepts Data Cards:</strong> 1 microSD™ card (32 GB maximum size)</p><p><strong>Waypoints:</strong> 5,000</p><p><strong>Track Points:</strong> 50,000</p><p><strong>Tracks:</strong> 50 saved tracks</p><p><strong>Navigation Routes:</strong> 100</p><h3>Sensors</h3><p><strong>GPS:</strong> Yes</p><p><strong>Galileo:</strong> Yes</p><p><strong>Built-in Receiver:</strong> Yes</p><p><strong>Receiver:</strong> 5 Hz</p><p><strong>Supports WAAS:</strong> Yes</p><h3>Built-in Maps</h3><p><strong>Built-in Auto Guidance+:</strong> Yes (downloadable via ActiveCaptain app)</p><p><strong>Garmin Navionics+ Inland & Coastal:</strong> Yes (see Additional)</p><p><strong>Garmin Navionics+ (Coastal):</strong> Yes (see Additional)</p><p><strong>Garmin Navionics+ (Inland):</strong> Yes (see Additional)</p><p><strong>Tide Tables:</strong> Yes (see Additional)</p><h3>Optional Map Support</h3><p><strong>Supported Maps:</strong> • BlueChart g3 • BlueChart g3 Vision • LakeVü g3 • LakeVü g3 Ultra • Garmin Navionics+™ • Garmin Navionics Vision+™ • TOPO 100K • Standard Mapping • Garmin Quickdraw Contours</p><h3>Chartplotter Features</h3><p><strong>ActiveCaptain® Compatible:</strong> Yes</p><h3>Electrical Features</h3><p><strong>Power Input:</strong> 9 to 18 Vdc</p><p><strong>Typical Current Draw at 12 Vdc:</strong> 1.0 A</p><p><strong>Maximum Current Draw at 12 Vdc:</strong> 1.5 A</p><p><strong>Maximum Power Usage at 10 Vdc:</strong> 18W</p><h3>Sonar Features</h3><p><strong>Displays Sonar:</strong> Yes</p><p><strong>Power Output:</strong> 500 W</p><p><strong>Traditional Sonar (Dual Frequency/Beam):</strong> Built-in (single channel CHIRP, 50/77/83/200 kHz, L, M, H CHIRP)</p><p><strong>ClearVü:</strong> Built-in 260/455/800/1000/1200 kHz</p><h3>Connections</h3><p><strong>4-Pin Transducer Ports:</strong> 1</p><p><strong>Garmin Wi-Fi Network (Local Connection):</strong> Yes</p></div>
