<div class="metafield-rich_text_field"><h3>General</h3><p><strong>Dimensions:</strong> 8.1" x 5.2" x 2.6" (20.6 x 13.1 x 6.7 cm)</p><p><strong>Weight:</strong> 1.8 lbs (0.8 kg)</p><p><strong>Water Rating:</strong> IPX7</p><p><strong>Touchscreen:</strong> Yes</p><p><strong>Display:</strong> • Type: WVGA, TN • Size: 5.4" x 3.1", 6.2" (13.8 x 7.8, 15.7 cm) • Resolution: 800 x 480 pixels</p><p><strong>Mounting Options:</strong> Bail or flush</p><p><strong>Input:</strong> Touchscreen with Keyed Assist</p><h3>Maps & Memory</h3><p><strong>Accepts Data Cards:</strong> 1 microSD™ card; 32 GB maximum size</p><p><strong>Waypoints:</strong> 5,000</p><p><strong>Tracks:</strong> • Track Points: 50,000 • Saved Tracks: 50</p><p><strong>Navigation Routes:</strong> 100</p><h3>Sensors</h3><p><strong>GPS:</strong> Yes</p><p><strong>GLONASS:</strong> Yes</p><p><strong>Galileo:</strong> Yes</p><p><strong>BeiDou:</strong> Yes</p><p><strong>Built-In Receiver:</strong> Yes</p><p><strong>Receiver Update Rate:</strong> 10 Hz</p><p><strong>NMEA 2000 Compatible:</strong> Yes</p><p><strong>Supports WAAS:</strong> Yes</p><p><strong>Supports Multi-Band, Multi-Constellation GPS:</strong> Yes</p><h3>Built-in Maps</h3><p><strong>Built-in Auto Guidance+:</strong> Yes (downloadable via ActiveCaptain app)</p><p><strong>Garmin Navionics+ Inland & Coastal:</strong> Yes (see Additional)</p><p><strong>Garmin Navionics+ (Coastal):</strong> Yes (see Additional)</p><p><strong>Garmin Navionics+ (Inland):</strong> Yes (see Additional)</p><p><strong>Tide Tables:</strong> Yes (see Additional)</p><h3>Optional Map Support</h3><p><strong>BlueChart g3:</strong> Yes</p><p><strong>BlueChart g3 Vision:</strong> Yes</p><p><strong>LakeVü g3:</strong> Yes</p><p><strong>LakeVü g3 Ultra:</strong> Yes</p><p><strong>Garmin Navionics+™:</strong> Yes</p><p><strong>Garmin Navionics Vision+™:</strong> Yes</p><p><strong>TOPO 100K:</strong> Yes</p><p><strong>Standard Mapping:</strong> Yes</p><p><strong>Garmin Quickdraw Contours:</strong> Yes</p><h3>Chartplotter Features</h3><p><strong>AIS:</strong> Yes</p><p><strong>DSC:</strong> Yes</p><p><strong>Supports Fusion-Link™ Compatible Radios:</strong> Yes</p><p><strong>ActiveCaptain® Compatible:</strong> Yes</p><p><strong>Sailing Features:</strong> Yes</p><h3>Electrical Features</h3><p><strong>Power Input:</strong> 9 to 18 Vdc</p><p><strong>Typical Current Draw (at 12 Vdc):</strong> 1.53 A</p><p><strong>Maximum Current Draw (at 12 Vdc):</strong> 3.2 A</p><p><strong>Maximum Power Usage (at 10 Vdc):</strong> 18.4W</p><h3>Sonar Features</h3><p><strong>Displays Sonar:</strong> Yes</p><p><strong>Power Output:</strong> 500 W</p><p><strong>Traditional Sonar (Dual Frequency/Beam):</strong> Built-in (single channel CHIRP, 50/77/83/200 kHz, L, M, H CHIRP)</p><p><strong>ClearVü:</strong> Built-in 260/455/800/1000/1200 kHz</p><p><strong>SideVü:</strong> Built-in 260/455/800/1000/1200 kHz</p><p><strong>Panoptix™ Sonar:</strong> Yes</p><p><strong>LiveScope:</strong> Yes</p><h3>Connections</h3><p><strong>NMEA 2000® Ports:</strong> Yes</p><p><strong>Garmin Marine Network Ports:</strong> 1</p><p><strong>12-Pin Transducer Ports:</strong> 1</p><p><strong>Bluetooth® Pairing:</strong> Yes</p><p><strong>ANT® (Connectivity):</strong> Yes </p><p><strong>Garmin Wi-Fi Network (Local Connection):</strong> Yes</p></div>
